CAT7 S/FTP Lan Cable Category Cable

Lan Cable is a kind of media for transmitting digital information. This kind of cable is used in building integrated cabling system, residential integrated cabling system and enterprise information network cabling system. It is suitable for the front end of broadband and high-speed networks.

Message form contact us

PREV: No previous article NEXT: No next article

Details & specifications

Construction
Technical Data Sheet
Documents to download

Item		Unit	Spec. Value
Conductor	Wire No.	---	4P
	Material	---	Solid Bare Copper
	Spec	AWG	23AWG
	Construction	No./mm	0.57±0.02
Insulation	Material	---	Skin-foam-skin
	Diameter	mm	1.35±0.05
	Color	---	1.Blue&White 2.Orange&White 3.Green&White 4.Brown&White
Foil Shield	Spec	mm	AL-Mylar 100％Coverage
Drain Wire	Material	---	Tinned copper
Drain Wire	Spec	mm	1/0.4±0.05
Braid Shield	Material	---	Al-Mg ＞40％Coverage
Jacket	Material	---	PVC
	Color	---	Assorted upon request
	Thickness	mm	0.55±0.1
	Diameter	mm	7.8±0.5

Zhejiang Wanma Tianyi Communication Wire & Cable Co., Ltd.

Certification

Color Printing Packaging Line, Imported New High-end Printing Equipment

lEAVE A MESSAGE

News

Optoelectronic composite cable: Pioneer in the integration of communications and power

Today, with the rapid development of big data, cloud computing and Internet of Things technologies, communicat...
2024-04-18
Compatibility of video cable power distribution accessories: key to ensuring stable signal transmission

With the continuous development of audio and video technology, the selection of video cable distribution acces...
2024-04-11
Wall-mounted fiber optic terminal box power distribution accessories: dual guarantee of ease of use and stability

In modern communication networks, wall-mounted optical fiber terminal box power distribution accessories provi...
2024-04-04
High-performance messenger, jelly-filled quad-shielded coaxial cables boost signal transmission

With the rapid development of technology, the demand for television signal transmission, radio communication, ...
2024-03-28

Product knowledge extension

The CAT7 S/FTP Lan Cable features a fully shielded design that offers superior protection against electromagnetic interference (EMI) and radio frequency interference (RFI). The cable is designed to meet and exceed the latest Category 7 standards, which means it can deliver speeds of up to 10Gbps over distances of up to 100 meters.

The cable is constructed with four pairs of twisted copper wires, each with its own individual shielding. This design minimizes crosstalk and ensures the highest level of signal integrity. The cable is also compatible with all previous generations of Ethernet cables, including CAT6 and CAT5e, ensuring easy integration with existing networks.

The outer sheath of the CAT7 S/FTP Lan Cable is made from a high-quality, flame-retardant PVC material, ensuring maximum safety in case of fire. The cable is also UV-resistant and can withstand exposure to direct sunlight and other environmental factors, making it ideal for both indoor and outdoor applications.

Installation of the CAT7 S/FTP Lan Cable is easy and straightforward, thanks to its standardized RJ45 connectors. The connectors are gold-plated to ensure a secure and reliable connection that won't degrade over time. The cable is also fully backward compatible with existing RJ45 connectors, making it easy to integrate into any network infrastructure.

In addition to its outstanding performance and reliability, the CAT7 S/FTP Lan Cable is also designed with the environment in mind. The cable is RoHS compliant, meaning it is free from hazardous substances that can harm the environment or human health. The cable is also fully recyclable, making it an eco-friendly choice for businesses and individuals alike.

The CAT7 S/FTP Lan Cable is available in a range of lengths, from 1 meter to 100 meters, to suit a variety of networking needs. The cable is also available in a variety of colors, including black, blue, and white, making it easy to match with any decor or environment.

Conductor Elongation	≥10％
Insulation Tensile Strength	≥10Mpa
Insulation Elongation	≥200％
Jacket Tensile Strength	≥13.8Mpa
Jacket Elongation	≥100％

Impedance	100±15Ω（1-100MHz）
	100±22Ω（100-250MHz）
	100±25Ω（250-600MHz）
Conductor Resistance @20°C	Max.9.38Ω/100m
DC Resistance Unbalance	Max.5％
Insulation Resistance	Min. 5000 MΩ*Km
Delay Skew	Max.25ns/100m

Frequency（MHz）	ATT (≤dB)	NEXT (≥dB)	PSNEXT (≥dB)	ELFEXT (≥dB)	PS ELFEXT (≥dB)	Delay (≤ns)	RL (≥dB)	Spread out 100m cable and test it
1.00	2,1	78.0	75.0	78.0	75.0	570.0	20.0
4.00	3.7	78.0	75.0	78.0	75.0	552.0	23.0
8.00	5.2	78.0	75.0	77.2	74.2	547.0	24.5
10.00	5.8	78.0	75.0	75.3	72.3	545.0	25.0
16.00	7.3	78.0	75.0	71.2	68.2	543.0	25.0
20.00	8.2	78.0	75.0	69.3	66.3	542.0	25.0
25.00	9.2	78.0	75.0	67.3	64.3	541.0	24.3
31.25	10.3	78.0	75.0	65.4	62.4	540.0	23.6
62.50	14.6	78.0	75.0	59.4	56.4	539.0	21.5
100.00	18.5	75.4	72.4	55.3	52.3	538.0	20.1
200.00	26.5	70.9	69.8	49.3	46.3	537.0	18.0
250.00	29.7	69.4	67.9	47.3	44.3	536.0	17.3
300.00	32.7	68.2	66.4	45.8	42.8	536.0	17.3
400.00	38.0	66.4	65.2	43.3	40.3	536.0	17.3
500.00	42.8	64.9	63.4	41.3	38.3	536.0	17.3
600.00	47.1	63.7	61.9	39.7	36.7	535.0	17.3
